Food/Cuff Passes

7270 SideWinder for #17 Snaplatch Lock

Description:

The 7270 SideWinder Food/Cuff Pass Door was designed to be welded to any existing hollow metal door that has a either a mesh or glass insert located 5"-10" above the lock centerline of the door. It's horizontal profile will fit at the appropriate height on the door, the vision panel will not be obstructed with the lock. It will allow for inmate cuffing or food trays to be passed directly to the inmate without having to open the secure cell door and breaching the guards or inmates security.

This Food/Cuff Pass-Thru is manufactured using 10ga(.135") for the frame and 7ga(.179") for the door with a 10ga(.135") stiffener, heavy duty hinges w/removable stops and security torx screws. They are factory preped for a #17 Snap Latch Lock(quoted separate, see Hardware & Locks tab above) this requires a guard with the key to unlock the pass door, remove and secure the key then shut the Food/Cuff Pass door.

Standard Specifications:

Pass-Thru opening: 15" x 5"

Overall size: 22" x 10"

Lock Prep: #17 Snap Latch

Door Handing: L / R see the Door Handing Chart to properly hand the door

Door thickness range: -2.0 for 2.0" door -1.7 for 1 3/4" door

Finish: -X Powdercoat Primer/Gray ready for paint

Material: -M0 HR Steel

Options Available:

Special Finish: -S Powder Coated in Cardinal Standard Colors from Powder Color Brochure below - Up Charge

Stainless Steel: -M8 3cr12, -M5 304-2B Mill Finish, -M6 304-#4 Brushed Finish - Up-Charge
